How to remove and replace the control arm on Volkswagen GTI?

To loosen the driveaxle/hub bolt (hub bolt may or may not be present), loosen the driveaxle/hub bolt by 1/4-turn when the vehicle is on its wheels and then loosen the wheel bolts. Lift the front of the car and put it on jackstands and block the back wheels to prevent rolling. Loose the wheel and driveaxle/hub bolt, the balljoint-to-control arm nuts. Draw the control arm downwards to disengage it with the balljoint, and, if it has one, disconnect the front level control sensor arm with the control arm. In the right side control arm, you would remove the horizontal control arm pivot bolt on the front side and the vertical control arm mounting bolt and nut on the rear side and then work the arm to the rear and pull it out. In the case of the left side control arm, eliminate the pendulum mount, unscrew the steering column U-joint coupler on the steering gear, unscrew the support bracket fasteners of the exhaust pipe, and unclip the power steering pressure line. Take away the horizontal control arm bolt on the front and vertical nut and bolt at the back. Removal of pivot bolt To remove pivot bolt, place a floor jack under the subframe, take out the two outermost subframe-to-body bolts, looseen the front subframe bolts and lower the rear by not more than 3-15/16 inches. Take the control arm out of the subframe, and clean it well, looking after any cracks or wear, but particularly in the inner pivot bushings. Replacement of bushing involves a hydraulic press and best done at a machine shop in the automotive shop, press out the old bushing and install the new one ensuring that it fits into position. To install, remove all parts in the reverse order, with new fasteners, bring the outer end of the control arm to the approximate normal ride height to be ensured, then tighten all of the suspension fasteners to recommended torque values, secure the vehicle on the ground, and tighten the wheel bolts and have the front end alignment checked and adjusted as required.

Genuine Volkswagen GTI Control Arm

Suspension Arm

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

12 Control Arms found

View related parts
Volkswagen GTI Lower Control Arm Part Number: 5WA-505-311-A
$118.69 MSRP: $166.24
You Save: $47.55 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2022-2024 Volkswagen GTI | 40th Anniversary Edition, Autobahn, S, SE | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Upper Control Arm Part Number: 1K0-505-323-N
$176.43 MSRP: $247.10
You Save: $70.67 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm; Torque Arm
- Position: Upper
- Replaces: 1K0-505-323-H, 1K0-505-323-M
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2014 Volkswagen GTI | Base, Driver's Edition, Fahrenheit, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 1K0-407-152-BC
$216.25 MSRP: $302.87
You Save: $86.62 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Position: Right
- Replaces: 1K0-407-152-AA, 1K0-407-152-AH, 1K0-407-152-P
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2014 Volkswagen GTI | Base, Driver's Edition, Fahrenheit, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 1K0-407-151-BC
$223.65 MSRP: $313.24
You Save: $89.59 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Position: Left
- Replaces: 1K0-407-151-P, 1K0-407-151-AA, 1K0-407-151-AE, 1K0-407-151-AH
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2014 Volkswagen GTI | Base, Driver's Edition, Fahrenheit, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Upper Control Arm Part Number: 5Q0-505-323-C
$229.90 MSRP: $321.98
You Save: $92.08 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm; Torque Arm, Upper Link
- Position: Upper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2013-2024 Volkswagen GTI | 40th Anniversary Edition, Autobahn, Base, Driver's Edition, Rabbit Edition, S, SE, Sport, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 1K0-407-151-AC
$237.39 MSRP: $332.48
You Save: $95.09 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Position: Left
- Replaces: 1K0-407-151-M
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen GTI | Base | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 1K0-407-152-AC
$237.39 MSRP: $332.48
You Save: $95.09 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Position: Right
- Replaces: 1K0-407-152-M
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen GTI | Base | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Lower Control Arm Part Number: 1K0-505-311-AB
$251.06 MSRP: $342.98
You Save: $91.92 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm
- Position: Lower
- Replaces: 1K0-505-311-S, 1K0-505-311-AA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2014 Volkswagen GTI | Base, Driver's Edition, Fahrenheit, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 5WA-407-152
$281.81 MSRP: $384.98
You Save: $103.17 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm, Lower Control Arm
- Position: Right
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2022-2024 Volkswagen GTI | 40th Anniversary Edition, Autobahn, S, SE | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 5QM-407-151-C
$345.76 MSRP: $472.34
You Save: $126.58 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015-2021 Volkswagen GTI | Autobahn, Rabbit Edition, S, SE, Sport | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Control Arm Part Number: 5QM-407-152-C
$352.68 MSRP: $481.79
You Save: $129.11 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015-2021 Volkswagen GTI | Autobahn, Rabbit Edition, S, SE, Sport | 4 Cyl 2.0 L GAS
View related parts
Volkswagen GTI Lower Control Arm Part Number: 5QM-505-311
$568.04 MSRP: $776.02
You Save: $207.98 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Control Arm
- Position: Lower
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015-2021 Volkswagen GTI | Autobahn, Rabbit Edition, S, SE, Sport | 4 Cyl 2.0 L GAS

Volkswagen GTI Control Arm

Choose OEM Control Arm for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Control Arm on your GTI, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen GTI parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen GTI Control Arm Parts and Q&A

Upper Control Arm
5Q0-505-323-C
Q: How to remove and replace the control arm on Volkswagen GTI?
A:
To loosen the driveaxle/hub bolt (hub bolt may or may not be present), loosen the driveaxle/hub bolt by 1/4-turn when the vehicle is on its wheels and then loosen the wheel bolts. Lift the front of the car and put it on jackstands and block the back wheels to prevent rolling. Loose the wheel and driveaxle/hub bolt, the balljoint-to-control arm nuts. Draw the control arm downwards to disengage it with the balljoint, and, if it has one, disconnect the front level control sensor arm with the control arm. In the right side control arm, you would remove the horizontal control arm pivot bolt on the front side and the vertical control arm mounting bolt and nut on the rear side and then work the arm to the rear and pull it out. In the case of the left side control arm, eliminate the pendulum mount, unscrew the steering column U-joint coupler on the steering gear, unscrew the support bracket fasteners of the exhaust pipe, and unclip the power steering pressure line. Take away the horizontal control arm bolt on the front and vertical nut and bolt at the back. Removal of pivot bolt To remove pivot bolt, place a floor jack under the subframe, take out the two outermost subframe-to-body bolts, looseen the front subframe bolts and lower the rear by not more than 3-15/16 inches. Take the control arm out of the subframe, and clean it well, looking after any cracks or wear, but particularly in the inner pivot bushings. Replacement of bushing involves a hydraulic press and best done at a machine shop in the automotive shop, press out the old bushing and install the new one ensuring that it fits into position. To install, remove all parts in the reverse order, with new fasteners, bring the outer end of the control arm to the approximate normal ride height to be ensured, then tighten all of the suspension fasteners to recommended torque values, secure the vehicle on the ground, and tighten the wheel bolts and have the front end alignment checked and adjusted as required.
