How to replace the Axle Shaft Seal on Volkswagen Jetta?

In order to change the drive flange oil seals in the front-wheel-drive versions, first loosen the wheel bolts and the driveaxle/hub bolts, apply the parking brake, lift the front of the car, and place it in a safe position on jackstands and remove the wheel. Then pull out the driveaxle and unbolt the heat shield of the right side driveaxle and on 6-speed models, the inner fender liner may have to be taken out to reach it. Place an assembly under the transaxle to receive any spilled oil, and then remove the mounting bolt in the center of the drive flange, screwing two bolts into the flange, and gripping it with a prybar. When the flange and compression spring are removed, record the installed depth of the oil seal and pry it out by using a large flat-bladed screwdriver. Wipe area around the oil seal opening, grease lips of the new oil seal, and carefully fit in place making sure that the sealing lip is facing inwards then tap into place with an appropriate tubular drift. Wipe the oil seal and grease the lips and then slide the drive flange with the compression spring through the oil seal connecting it to the differential gear. Install and tighten the flange mounting bolt, reattach the driveaxle and then the wheel and lower the vehicle checking the transaxle oil level. In the case of the selector shaft oil seal, get the parking brake in place, elevate the front of the car and place it on jackstands. Should you need to replace the air filter housing, it may be removed to expose the shift lever at the transaxle, unscrew the locking nut and slide the shift lever off the selector shaft. An oil seal may be carefully peeled off the housing without injuring the selector shaft or housing, clean the seating and shaft, and apply multi-purpose grease on the new oil seal lips before returning it to its place over the end of the shaft with the closed side outwards. To avoid damage, tape up the end of the shaft with adhesive tape and then press the oil seal into place with the help of an appropriate tubular drift. And lastly, fit the gearshift coupling, screw up the locking link and bring the vehicle to the ground.

Genuine Volkswagen Jetta Axle Shaft Seal

CV Axle Seal

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

7 Axle Shaft Seals found

View related parts
Volkswagen Jetta Seal Part Number: 5Q0-698-471
$25.57 MSRP: $42.61
You Save: $17.04 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Seal Kit, Seal, Seal Kit
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2019-2024 Volkswagen Jetta | GLI 35th Anniversary Edition, GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Jetta Seal Part Number: 5Q0-698-471-B
$25.57 MSRP: $42.61
You Save: $17.04 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Seal Kit, Seal, Seal Kit
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2019-2024 Volkswagen Jetta | GLI 35th Anniversary Edition, GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Jetta Seal Kit Part Number: 8D0-698-671
$33.24 MSRP: $55.40
You Save: $22.16 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Seal Kit, Overhaul Kit, Seal Kit
- Replaces: 535-698-671
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2011-2018, 1991-2001 Volkswagen Jetta | Base, Carat, Celebration Edition, City, GL, GLI, GLI 16-Valve, GLI SE, GLI SEL, GLS, GLX, GT, Hybrid, Hybrid SE, Hybrid SEL, Hybrid SEL Premium, Jazz, K2, S, SE, SE Sport, SEL, SEL Premium, Sport, TDI, TDI Premium, TDI S, TDI SE, TDI SEL, Trek, Wolfsburg Edition | 4 Cyl 1.4 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 1.4 L GAS, 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Seal Part Number: 357-501-641-B
$27.83 MSRP: $46.38
You Save: $18.55 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Replaces: 357-501-641-C
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1985-1999 Volkswagen Jetta | Base, Carat, Celebration Edition, City, GL, GLI, GLI 16-Valve, GLS, GLX, GT, Jazz, K2, Limited Edition, TDI, Trek, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Seal Kit Part Number: 5K0-698-671-C
$28.60 MSRP: $47.65
You Save: $19.05 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Overhaul Kit, Caliper Seal Kit, Seal Kit
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2010-2018 Volkswagen Jetta | Base, GLI, GLI SE, GLI SEL, Hybrid, Hybrid SE, Hybrid SEL, Hybrid SEL Premium, S, SE, SE Sport, SEL, SEL Premium, Sport, TDI, TDI Premium, TDI S, TDI SE, TDI SEL, Wolfsburg Edition | 4 Cyl 1.4 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 1.4 L GAS, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS
View related parts
Volkswagen Jetta Seal Kit Part Number: 1J0-698-671
$19.89 MSRP: $32.60
You Save: $12.71 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Seal Kit, Seal Kit
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2001-2010 Volkswagen Jetta | 2.0T, 2.5, GL, GL TDI, GLI, GLS, GLS TDI, GLX, S, SE, SEL, TDI, Value Edition, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Seal Kit Part Number: 8N0-698-471
$51.14 MSRP: $71.04
You Save: $19.90 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Set Seals; Caliper Seal Kit, Overhaul Kit, Seal Kit
- Replaces: 1J0-698-471
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2011-2016, 2001-2005 Volkswagen Jetta | Base, GL, GL TDI, GLI, GLI SE, GLI SEL, GLS, GLS TDI, GLX, Hybrid, Hybrid SE, Hybrid SEL, Hybrid SEL Premium, S, SE, SEL, SEL Premium, Sport, TDI, TDI Premium, TDI S, TDI SE, TDI SEL, Wolfsburg Edition | 4 Cyl 1.4 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 1.4 L GAS, 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS, 6 Cyl 2.8 L GAS

Volkswagen Jetta Axle Shaft Seal

Choose OEM Axle Shaft Seal for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Axle Shaft Seal on your Jetta, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen Jetta parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen Jetta Axle Shaft Seal Parts and Q&A

Seal Kit
5K0-698-671-C
Q: How to replace the Axle Shaft Seal on Volkswagen Jetta?
A:
In order to change the drive flange oil seals in the front-wheel-drive versions, first loosen the wheel bolts and the driveaxle/hub bolts, apply the parking brake, lift the front of the car, and place it in a safe position on jackstands and remove the wheel. Then pull out the driveaxle and unbolt the heat shield of the right side driveaxle and on 6-speed models, the inner fender liner may have to be taken out to reach it. Place an assembly under the transaxle to receive any spilled oil, and then remove the mounting bolt in the center of the drive flange, screwing two bolts into the flange, and gripping it with a prybar. When the flange and compression spring are removed, record the installed depth of the oil seal and pry it out by using a large flat-bladed screwdriver. Wipe area around the oil seal opening, grease lips of the new oil seal, and carefully fit in place making sure that the sealing lip is facing inwards then tap into place with an appropriate tubular drift. Wipe the oil seal and grease the lips and then slide the drive flange with the compression spring through the oil seal connecting it to the differential gear. Install and tighten the flange mounting bolt, reattach the driveaxle and then the wheel and lower the vehicle checking the transaxle oil level. In the case of the selector shaft oil seal, get the parking brake in place, elevate the front of the car and place it on jackstands. Should you need to replace the air filter housing, it may be removed to expose the shift lever at the transaxle, unscrew the locking nut and slide the shift lever off the selector shaft. An oil seal may be carefully peeled off the housing without injuring the selector shaft or housing, clean the seating and shaft, and apply multi-purpose grease on the new oil seal lips before returning it to its place over the end of the shaft with the closed side outwards. To avoid damage, tape up the end of the shaft with adhesive tape and then press the oil seal into place with the help of an appropriate tubular drift. And lastly, fit the gearshift coupling, screw up the locking link and bring the vehicle to the ground.
