How to remove and install the steering column on Volkswagen Jetta?

The steering column is removed by first straightening the wheels by parking the car and in automatic transmission models, the shift lever is put in PARK. Unplug the cable on the negative battery terminal and deactivate the airbag system. Unscrew the steering column covers and the steering wheel being careful not to rotate the steering shaft. Unscrew the lower instrument panel trim, which is below the steering column and remove the multi-function switch. Unscrew the wiring harness clips, connectors and ground wire on the steering column. To remove the cable guide cover, push the tabs on both sides of the cable guide. In manual transmission models, all models have a crash brace fastener and brace over the pedal clutch. Use a length of wire to fasten the bottom part of the steering column to the top part. Take off the footwell trim panel, identify the relative position of the steering shaft lower universal joint relative to the steering gear input shaft, and loosen the pinch bolt which holds the universal joint in place. The next step would be to take out the steering column mounting bolts, detach the universal joint, and the steering gear input shaft and then run the column out of the instrument panel. To install, insert the column into place and attach the U-joint with the steering gear input shaft and fit the pinch bolt without tightening it. Fit the steering column mounting bolts but do not screw them at this point. Take out the wire and in the event that a new steering column was fitted strip out all the protective material applied on it during transportation. Installation Installation is completed by reversing steps of removal with the exception of the airbag clockspring in the steering wheel assembly, which should be installed centered and the steering wheel bolt tightened to the prescribed torque, the column mounting bolts and lastly tightening the U-joint pinch bolt when the column mounting fasteners are firmly in place.

Genuine Volkswagen Jetta Steering Column

Steering Column Tilt

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Steering Columns found

View related parts
Volkswagen Jetta Jacket Part Number: 191-419-503-A
$139.13 MSRP: $194.87
You Save: $55.74 (29%)
ADD TO CART
Product Specifications
- Other Name: Steer Column; Jacket, Shaft, Upper Shaft
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1985-1992 Volkswagen Jetta | Base, Carat, GL, GLI, GLI 16-Valve, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Jetta Shaft Part Number: 1H0-419-503-A
$176.93 MSRP: $247.80
You Save: $70.87 (29%)
ADD TO CART
Product Specifications
- Other Name: Steer Column; Shaft, Steering Column
- Position: Upper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1993-1999 Volkswagen Jetta | Base, Celebration Edition, City, GL, GLS, GLX, GT, Jazz, K2, Limited Edition, TDI, Trek, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 1K1-419-502-CJ
$77.05 MSRP: $107.92
You Save: $30.87 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column; Column Assembly, Steering Column
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2009-2010 Volkswagen Jetta | GLI, S, SE, SEL, TDI, TDI Cup Edition, Wolfsburg Edition | 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS
View related parts
Volkswagen Jetta Column Assembly Part Number: 1J1-419-501-ER
$469.70 MSRP: $641.67
You Save: $171.97 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column
- Replaces: 1J1-419-501-DD, 1J1-419-501-EK, 1J1-419-501-DK
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1999-2005 Volkswagen Jetta | GL, GL TDI, GLI, GLS, GLS TDI, GLX, TDI, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 5QM-419-502-AS
$658.79 MSRP: $830.76
You Save: $171.97 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2019-2024 Volkswagen Jetta | GLI 35th Anniversary Edition, GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 1J1-419-501-EQ
$498.42 MSRP: $680.89
You Save: $182.47 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column; Column Assembly
- Replaces: 1J1-419-501-DQ, 1J1-419-501-DC, 1J1-419-501-EJ, 1J1-419-501-DJ
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1999-2005 Volkswagen Jetta | GL, GL TDI, GLI, GLS, GLS TDI, GLX, TDI, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 5QM-419-502-AT
$628.59 MSRP: $792.68
You Save: $164.09 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2021-2022 Volkswagen Jetta | GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 1J1-419-501-FM
$765.54 MSRP: $965.37
You Save: $199.83 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column; Column Assembly
- Replaces: 1J1-419-501-FH, 1J1-419-501-DR, 1J1-419-501-ET, 1J1-419-501-FB
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1999-2005 Volkswagen Jetta | GL, GL TDI, GLI, GLS, GLS TDI, GLX, TDI, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 1K1-419-502-AB
$599.39 MSRP: $818.83
You Save: $219.44 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column; Steering Column
- Replaces: 1K1-419-502-AA, 1K1-419-502-R
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2005-2009 Volkswagen Jetta | 2.0T, 2.5, GL, GL TDI, GLI, GLS, GLS TDI, S, SE, SEL, TDI, Value Edition, Wolfsburg Edition | 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS
View related parts
Volkswagen Jetta Steering Column Part Number: 1K1-419-502-CT
$823.49 MSRP: $1038.45
You Save: $214.96 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Steer Column
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2010-2018 Volkswagen Jetta | Base, GLI, GLI SE, GLI SEL, Hybrid, Hybrid SE, Hybrid SEL, Hybrid SEL Premium, S, SE, SE Sport, SEL, SEL Premium, Sport, TDI, TDI Premium, TDI S, TDI SE, TDI SEL, Wolfsburg Edition | 4 Cyl 1.4 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 1.4 L GAS, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L DIESEL, 4 Cyl 2.0 L GAS, 5 Cyl 2.5 L GAS

Volkswagen Jetta Steering Column

Choose OEM Steering Column for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Steering Column on your Jetta, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen Jetta parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen Jetta Steering Column Parts and Q&A

Steering Column
1K1-419-502-CT
Q: How to remove and install the steering column on Volkswagen Jetta?
A:
The steering column is removed by first straightening the wheels by parking the car and in automatic transmission models, the shift lever is put in PARK. Unplug the cable on the negative battery terminal and deactivate the airbag system. Unscrew the steering column covers and the Steering Wheel being careful not to rotate the steering shaft. Unscrew the lower instrument panel trim, which is below the steering column and remove the multi-function switch. Unscrew the wiring harness clips, connectors and ground wire on the steering column. To remove the cable guide cover, push the tabs on both sides of the cable guide. In manual transmission models, all models have a crash brace fastener and brace over the pedal clutch. Use a length of wire to fasten the bottom part of the steering column to the top part. Take off the footwell trim panel, identify the relative position of the steering shaft lower universal joint relative to the steering gear input shaft, and loosen the pinch bolt which holds the universal joint in place. The next step would be to take out the steering column mounting bolts, detach the universal joint, and the steering gear input shaft and then run the column out of the instrument panel. To install, insert the column into place and attach the U-joint with the steering gear input shaft and fit the pinch bolt without tightening it. Fit the steering column mounting bolts but do not screw them at this point. Take out the wire and in the event that a new steering column was fitted strip out all the protective material applied on it during transportation. Installation Installation is completed by reversing steps of removal with the exception of the airbag clockspring in the steering wheel assembly, which should be installed centered and the steering wheel bolt tightened to the prescribed torque, the column mounting bolts and lastly tightening the U-joint pinch bolt when the column mounting fasteners are firmly in place.
