What should be checked for damage and wear in seat belts, and How to verify the seat belt reminder light on Volkswagen Rabbit?

Obvious damage and signs of wear are found on check seat belts, buckles, and latch plates and guide loops. Make sure that the bolts that are connecting the seat belt receptacle to the floor of the vehicle are tight. Check that the seat belt reminder light should work by opening the key to the Run or Start position.

What precautions should be taken when disconnecting the battery and replacing seat belts on Volkswagen Rabbit?

When the battery is disconnected, a number of systems have to be re-learned before they can work well. In the case of front seat belts, one should first position the seat in the highest position and take off the negative battery cable. To disassemble the sill trim panel, open the front and rear doors, then remove the trim panel that is one piece on the front, to the rear door. Take out the airbag emblem with a small screw driver on the 8 pillar upper trim panel, and then remove the fastener and pry the panel off the pillar. Then take off the two fasteners at the bottom of the lower trim panel which has 8 pillars and remove the panel. Take out the belt anchor fastener and loosen the anchor out of the body. Following a small screwdriver, open the wire retainer, disconnect the electrical connector with the belt module, and remove the belt retractor fastener on the bottom of the 8-pillar and the belt tensioner. Unscrew the belt guide fasteners of the 8-pillar, loosen the guide and loosen the belt pivoting guide fastener of the height adjuster, then loosen the belt. Installation is the opposite of dismantling so that the belt is not twisted prior to attaching the lower side of the seat mount. To replace the belt latches, one has to remove the front seat and then loosen the latch fastener and the latch under the seat, and to install the belt latch, one has to do the same, but in reverse. In the case of rear seat belts, disconnect negative battery cable, undo the seat and disassemble lower anchor point fastener and end of belt. Installation Reimbursement Firm: Take away the C-pillar trim and rear parcel shelf trim in sedan models, and inside the rear luggage compartment, remove the trim and loosen the belt retractor fastener, and slides the tensioner assembly back, up, and out. Open the retainer (yellow) with a small screwdriver and unplug the electrical connector of the belt module. Installation is the opposite of dismantling so that the belt is not twisted prior to attaching the lower side of the seat mount. In case of replacing latch of a belt, the seat cushion and back can be removed and the latch fastener and the latch out of the floorpan can be removed, and the installation is the same as the removal except not to twist the belt, then the lower mount side can be installed.

Genuine Volkswagen Rabbit Seat Belt

Seat Safety Belt

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

14 Seat Belts found

View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K4-857-706-S-RAA
$192.78 MSRP: $270.00
You Save: $77.22 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K4-857-706-G-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2007 Volkswagen Rabbit | 2.5 | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-807-Q-RAA
$127.63 MSRP: $165.00
You Save: $37.37 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Center
- Replaces: 1K6-857-807-G-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-805-AD-RAA
$80.47 MSRP: $104.03
You Save: $23.56 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Replaces: 1K6-857-805-P-RAA, 1K6-857-805-G-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-806-AD-RAA
$80.47 MSRP: $104.03
You Save: $23.56 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K6-857-806-G-RAA, 1K6-857-806-P-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-807-AH-RAA
$155.51 MSRP: $201.05
You Save: $45.54 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Center
- Replaces: 1K6-857-807-F-RAA, 1K6-857-807-P-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K3-857-705-A-RAA
$198.63 MSRP: $256.80
You Save: $58.17 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2007 Volkswagen Rabbit | 2.5 | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K3-857-706-H-RAA
$211.09 MSRP: $272.91
You Save: $61.82 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K3-857-706-A-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2007 Volkswagen Rabbit | 2.5 | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K4-857-706-BB-RAA
$233.24 MSRP: $301.54
You Save: $68.30 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K4-857-706-AB-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen Rabbit | S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K3-857-705-T-RAA
$247.04 MSRP: $311.52
You Save: $64.48 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Replaces: 1K3-857-705-K-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen Rabbit | S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K3-857-706-AB-RAA
$264.63 MSRP: $333.71
You Save: $69.08 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K3-857-706-L-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen Rabbit | S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K4-857-705-AT-RAA
$256.92 MSRP: $323.98
You Save: $67.06 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Replaces: 1K4-857-705-AA-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2008-2009 Volkswagen Rabbit | S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-805-AC-RAA
$254.46 MSRP: $320.87
You Save: $66.41 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Replaces: 1K6-857-805-H-RAA, 1K6-857-805-R-RAA, 1K6-857-805-S-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K6-857-806-AC-RAA
$124.33 MSRP: $160.73
You Save: $36.40 (23%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Right
- Replaces: 1K6-857-806-R-RAA, 1K6-857-806-S-RAA, 1K6-857-806-H-RAA
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2009 Volkswagen Rabbit | 2.5, S | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Rabbit Lap & Shoulder Belt Part Number: 1K4-857-705-H-RAA
$167.33 MSRP: $200.87
You Save: $33.54 (17%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Seat Belt; Lap & Shoulder Belt
- Position: Left
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2007 Volkswagen Rabbit | 2.5 | 5 Cyl 2.5 L GAS

Volkswagen Rabbit Seat Belt

Choose OEM Seat Belt for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Seat Belt on your Rabbit, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen Rabbit parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen Rabbit Seat Belt Parts and Q&A

Lap & Shoulder Belt
1K3-857-705-A-RAA
Q: What should be checked for damage and wear in seat belts, and How to verify the seat belt reminder light on Volkswagen Rabbit?
A:
Obvious damage and signs of wear are found on check seat belts, buckles, and latch plates and guide loops. Make sure that the bolts that are connecting the seat belt receptacle to the floor of the vehicle are tight. Check that the seat belt reminder light should work by opening the key to the Run or Start position.
Lap & Shoulder Belt
1K3-857-705-T-RAA
Q: What precautions should be taken when disconnecting the battery and replacing seat belts on Volkswagen Rabbit?
A:
When the battery is disconnected, a number of systems have to be re-learned before they can work well. In the case of front seat belts, one should first position the seat in the highest position and take off the negative battery cable. To disassemble the sill trim panel, open the front and rear doors, then remove the trim panel that is one piece on the front, to the rear door. Take out the airbag emblem with a small screw driver on the 8 pillar upper trim panel, and then remove the fastener and pry the panel off the pillar. Then take off the two fasteners at the bottom of the lower trim panel which has 8 pillars and remove the panel. Take out the belt anchor fastener and loosen the anchor out of the body. Following a small screwdriver, open the wire retainer, disconnect the electrical connector with the belt module, and remove the belt retractor fastener on the bottom of the 8-pillar and the belt tensioner. Unscrew the belt guide fasteners of the 8-pillar, loosen the guide and loosen the belt pivoting guide fastener of the height adjuster, then loosen the belt. Installation is the opposite of dismantling so that the belt is not twisted prior to attaching the lower side of the seat mount. To replace the belt latches, one has to remove the front seat and then loosen the latch fastener and the latch under the seat, and to install the belt latch, one has to do the same, but in reverse. In the case of rear seat belts, disconnect negative battery cable, undo the seat and disassemble lower anchor point fastener and end of belt. Installation Reimbursement Firm: Take away the C-pillar trim and rear parcel shelf trim in sedan models, and inside the rear luggage compartment, remove the trim and loosen the belt retractor fastener, and slides the tensioner assembly back, up, and out. Open the retainer (yellow) with a small screwdriver and unplug the electrical connector of the belt module. Installation is the opposite of dismantling so that the belt is not twisted prior to attaching the lower side of the seat mount. In case of replacing latch of a belt, the seat cushion and back can be removed and the latch fastener and the latch out of the floorpan can be removed, and the installation is the same as the removal except not to twist the belt, then the lower mount side can be installed.
