How to remove and install the Valve Cover for Four-cylinder engines on Volkswagen Passat?

The engine cover is removed by first removing the piping of the PCV system and the combination valve, where present. Where appropriate, unscrew the clip on the crankcase breather hose and the bolts that hold the breather pipe in place on the engine then take off the pipe. The second step would be to remove the ignition coils and then the heat shield of the valve cover by loosening the nut and bolts. Take off upper timing belt cover and ground straps of valve cover and loosen the valve cover of the cylinder head by removing the holding nuts. Squeezed cover: Loosely hammer the cover with a block of wood and a hammer or carefully cut the seal with a flexible putty knife without damaging the surfaces that are used to seal them. To install, make sure that the mating surfaces of the housing or cylinder head and cover are clean using a gasket scraper and cleaning with lacquer thinner or acetone to avoid the leakage of oil. Check the rubber end plug and change it where necessary. Seal with RTV the corners of the camshaft front bearing cap and the ends of the camshaft drive chain tensioner as they would meet the cylinder head. Install a new valve cover gasket and the spark plug tube grommet gasket over the studs on the cylinder head with the index marks aligning with the end of the timing belt. Fit the valve cover and any brackets that have been removed and screw on the retaining nuts to the required screwdriver tightness. Lastly, install the rest of the parts, start the engine and verify no leakage of oil.

Genuine Volkswagen Passat Valve Cover

Cylinder Head Cover

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

14 Valve Covers found

View related parts
Volkswagen Passat Valve Cover Part Number: 037-103-469-N
$96.39 MSRP: $135.00
You Save: $38.61 (29%)
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 037-103-475-L
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1995-1996 Volkswagen Passat | GLS | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 028-103-469-E
$167.08 MSRP: $234.00
You Save: $66.92 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1996-1997 Volkswagen Passat | TDI | 4 Cyl 1.9 L DIESEL
View related parts
Volkswagen Passat Valve Cover Part Number: 06B-103-475-D
$173.50 MSRP: $243.00
You Save: $69.50 (29%)
ADD TO CART
Product Specifications
- Other Name: Cover
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1998-2001 Volkswagen Passat | GLS | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 058-103-475-F
$174.22 MSRP: $244.00
You Save: $69.78 (29%)
ADD TO CART
Product Specifications
- Other Name: Cover
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1998 Volkswagen Passat | GLS | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 078-103-471-R
$230.85 MSRP: $323.31
You Save: $92.46 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Position: Left
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1998-2005 Volkswagen Passat | 4 Motion, GL, GLS, GLS 4 Motion, GLX, GLX 4 Motion | 6 Cyl 2.8 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 03L-103-469-AD
$277.54 MSRP: $379.15
You Save: $101.61 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover; Valve Cover
- Replaces: 03L-103-469-S
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015 Volkswagen Passat | TDI SE, TDI SEL Premium | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Valve Cover Part Number: 06B-103-469-BA
$276.88 MSRP: $378.24
You Save: $101.36 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 06B-103-469-N
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2001-2002 Volkswagen Passat | GLS | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 038-103-469-AE
$292.79 MSRP: $399.99
You Save: $107.20 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 038-103-469-AJ, 038-103-469-R
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2004-2005 Volkswagen Passat | GL TDI, GLS TDI | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Valve Cover Part Number: 03L-103-469-R
$323.29 MSRP: $441.66
You Save: $118.37 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2014 Volkswagen Passat | TDI SE, TDI SEL, TDI SEL Premium | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Valve Cover Part Number: 07K-103-469-L
$372.09 MSRP: $508.32
You Save: $136.23 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 07K-103-469-D, 07K-103-469-F
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2014 Volkswagen Passat | S, SE, SEL, SEL Premium, Wolfsburg Edition | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 06F-103-469-K
$396.49 MSRP: $541.65
You Save: $145.16 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 06F-103-469-F, 06F-103-469-G
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2008 Volkswagen Passat | 2.0T, Komfort, Lux, Turbo, Value Edition, Wolfsburg Edition | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 07D-103-469-H
$431.88 MSRP: $590.00
You Save: $158.12 (27%)
ADD TO CART
Product Specifications
- Other Name: Cover
- Position: Left
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2002-2004 Volkswagen Passat | W8 | 8 Cyl 4.0 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 07D-103-470-H
$431.88 MSRP: $590.00
You Save: $158.12 (27%)
ADD TO CART
Product Specifications
- Other Name: Cover
- Position: Right
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2002-2004 Volkswagen Passat | W8 | 8 Cyl 4.0 L GAS
View related parts
Volkswagen Passat Valve Cover Part Number: 03H-103-429-L
$515.44 MSRP: $704.15
You Save: $188.71 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover
- Replaces: 03H-103-429-D, 03H-103-429-C, 03H-103-429-B, 03H-103-429-H
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2018, 2006-2008 Volkswagen Passat | 3.6, GT, SE, SEL Premium, VR6 | 6 Cyl 3.6 L GAS

Volkswagen Passat Valve Cover

Choose OEM Valve Cover for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Valve Cover on your Passat, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen Passat parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen Passat Valve Cover Parts and Q&A

Valve Cover
038-103-469-AE
Q: How to remove and install the Valve Cover for Four-cylinder engines on Volkswagen Passat?
A:
The engine cover is removed by first removing the piping of the PCV system and the combination valve, where present. Where appropriate, unscrew the clip on the crankcase breather hose and the bolts that hold the breather pipe in place on the engine then take off the pipe. The second step would be to remove the ignition coils and then the heat shield of the valve cover by loosening the nut and bolts. Take off upper timing belt cover and ground straps of valve cover and loosen the valve cover of the cylinder head by removing the holding nuts. Squeezed cover: Loosely hammer the cover with a block of wood and a hammer or carefully cut the seal with a flexible putty knife without damaging the surfaces that are used to seal them. To install, make sure that the mating surfaces of the housing or cylinder head and cover are clean using a gasket scraper and cleaning with lacquer thinner or acetone to avoid the leakage of oil. Check the rubber end plug and change it where necessary. Seal with RTV the corners of the camshaft front bearing cap and the ends of the camshaft drive chain tensioner as they would meet the cylinder head. Install a new valve cover gasket and the spark plug tube grommet gasket over the studs on the cylinder head with the index marks aligning with the end of the timing belt. Fit the valve cover and any brackets that have been removed and screw on the retaining nuts to the required screwdriver tightness. Lastly, install the rest of the parts, start the engine and verify no leakage of oil.
