How to remove and reinstall the rear Steering Knuckle and rear Wheel Hub in a vehicle's rear suspension components on Volkswagen Passat?

Relax the wheel bolts and rear driveaxle hub bolt and then raise the back of the vehicle and place it on jackstands to make sure it is firmly secured. The next step is to take off the rear brake caliper, mount and brake disc bearing in mind to hold the caliper with a piece of wire or a piece of string to keep the hose away. And continue with the removal of the ABS rear wheel speed sensor. Position the camber adjusting cam relative to the lower control arm to maintain the camber positioning during reassembly and unscrew the nut on the other end of the bolt, remove the eccentric washer and draw the bolt. Unscrew the nut and take off the track rod-to-rear knuckle bolt then the upper control arm-to-rear knuckle bolt and then disassemble the knuckle and hub assembly. To install, it is necessary to reverse the steps used to remove the items, but be sure to install new hardware and make the match marks on the camber adjusting cam and the lower control arm and do not tighten any suspension fastener until the rear suspension is raised to replicate normal ride height, which prevents distortion of the bushings. Lastly, fully screw all suspension fasteners to desired torques, put brake disc and mounting bracket with caliper onto the car, and screw the brake fasteners to the correct torque before installing the wheel, screwing the bolts secure, and lowering the vehicle then screwing the bolts to recommended tightness.

How to remove the hub and wheel bearing assembly when replacing the steering knuckle on Volkswagen Jetta?

Disassemble the hub and the wheel bearing when the steering knuckle is to be replaced. The first step is to remove the wheel cover and loosen the driveaxle/hub bolt when the vehicle is on wheels, and then loosen the wheel bolts. Put the rear wheels in chock, use the parking brake, lift up the front of the car and place it safely on jackstands before removal of the front wheel. Then loosen the driveaxle/hub bolt and the ABS wheel speed sensor and brake caliper without dismounting the hose, secured the caliper to the coil spring to prevent any strain on the hose. Loosen a few turns of the balljoint-to-steering knuckle nut and then remove the tie-rod end of the steering knuckle and the balljoint of the control arm and part the balljoint and knuckle. Disconnect the front level control sensor arm with the control arm, in case equipped. Take the strut-to-knuckle nut out and hammer and punch out the bolt, taking care to make the opening where the strut inserts into the knuckle open wide where this might happen. Gently remove the knuckle assembly outwards and push the driveaxle out of the hub with a soft faced hammer to tap the CV joint out or a puller to loosen it out. secured driveaxle. To install, first install the balljoint into the knuckle and tighten the new nut to the required torque. Apply multi-purpose grease to the splines of the driveaxle, and then insert the knuckle/hub assembly in place and connect it to the driveaxle stub shaft, put a new driveaxle/hub bolt in place but not tightened. Attach the strut to the knuckle, and enter it as far as possible into the bore, and apply and organize the new nut and bolt to the required torque. Install the control arm to the balljoint and install and tighten new nuts to the recommended torque. Insert the tie-rod end into the steering knuckle and attach and tighten the new retaining nut. Install the caliper disc and caliper tighten the caliper mounting bracket bolts and caliper guide pin/mounting bolts to designated torque. Essentially, last but not least, screw the driveaxle/hub bolt on safely, screw in the ABS wheel speed sensor, replace the wheel again, lower the vehicle to the ground, and screw the driveaxle/hub bolt and wheel bolts to the required torque.

Genuine Volkswagen Steering Knuckle

Front Steering Knuckle

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

121 Steering Knuckles found

View related parts
Volkswagen Knuckle Part Number: 5QM-407-255-A
$93.83 MSRP: $131.42
You Save: $37.59 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing; Knuckle
- Position: Left
- Replaced by: 5QM-407-255-B
Fits the following Volkswagen Models:
- Jetta | 2019-2024 | GLI 35th Anniversary Edition, GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
- Taos | 2022-2024 | S, SE, SEL | 4 Cyl 1.5 L GAS
View related parts
Volkswagen Knuckle Part Number: 5QN-505-436-A
$261.39 MSRP: $357.08
You Save: $95.69 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
Fits the following Volkswagen Models:
- Tiguan | 2021-2024 | S, SE, SE R-Line Black, SEL, SEL Premium R-Line, SEL R-Line | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Knuckle Part Number: 5QN-505-435-A
$291.78 MSRP: $398.60
You Save: $106.82 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
Fits the following Volkswagen Models:
- Tiguan | 2021-2024 | S, SE, SE R-Line Black, SEL, SEL Premium R-Line, SEL R-Line | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Knuckle Part Number: 171-407-255-B
$191.35 MSRP: $268.00
You Save: $76.65 (29%)
ADD TO CART
Product Specifications
- Other Name: Housing; Knuckle
- Position: Left
Fits the following Volkswagen Models:
- Cabriolet | 1985-1993 | Base, Bestseller, Boutique, Carat, Classic, Etienne Aigner, Wolfsburg Edition | 4 Cyl 1.8 L GAS
- Scirocco | 1985-1988 | 16-Valve, Base | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Knuckle Part Number: 171-407-256-A
$191.35 MSRP: $268.00
You Save: $76.65 (29%)
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
- Position: Right
Fits the following Volkswagen Models:
- Cabriolet | 1985 | Base | 4 Cyl 1.8 L GAS
- Golf | 1986 | Base, GTI | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
- Jetta | 1984-1986 | Base, GL, GLI | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.7 L GAS, 4 Cyl 1.8 L GAS
- Rabbit | 1984 | GL, GTI, L, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.7 L GAS, 4 Cyl 1.8 L GAS
- Rabbit Convertible | 1984 | Base, Wolfsburg Edition | 4 Cyl 1.8 L GAS
- Scirocco | 1984 | Base | 4 Cyl 1.8 L GAS
View More
View related parts
Volkswagen Knuckle Part Number: 5QM-505-435-C
$423.54 MSRP: $578.60
You Save: $155.06 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
Fits the following Volkswagen Models:
- Taos | 2022-2024 | S, SE, SEL | 4 Cyl 1.5 L GAS
View related parts
Volkswagen Knuckle Part Number: 5QM-505-436-C
$423.54 MSRP: $578.60
You Save: $155.06 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
Fits the following Volkswagen Models:
- Taos | 2022-2024 | S, SE, SEL | 4 Cyl 1.5 L GAS
View related parts
Volkswagen Knuckle Part Number: 171-407-256-B
$204.68 MSRP: $286.67
You Save: $81.99 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
- Position: Right
Fits the following Volkswagen Models:
- Cabriolet | 1985-1993 | Base, Bestseller, Boutique, Carat, Classic, Etienne Aigner, Wolfsburg Edition | 4 Cyl 1.8 L GAS
- Golf | 1985 | Base, GTI | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
- Scirocco | 1985-1988 | 16-Valve, Base | 4 Cyl 1.8 L GAS
View More
View related parts
Volkswagen Knuckle Part Number: 5QM-407-256-A
$252.72 MSRP: $345.24
You Save: $92.52 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing; Knuckle
- Position: Right
- Replaced by: 5QM-407-256-B
Fits the following Volkswagen Models:
- Jetta | 2019-2024 | GLI 35th Anniversary Edition, GLI Autobahn, GLI S, R-Line, S, SE, SEL, SEL Premium, Sport | 4 Cyl 1.4 L GAS, 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS
- Taos | 2022-2024 | S, SE, SEL | 4 Cyl 1.5 L GAS
View related parts
Volkswagen Knuckle Part Number: 191-407-256-C
$214.20 MSRP: $300.00
You Save: $85.80 (29%)
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
Fits the following Volkswagen Models:
- Golf | 1987-1992 | Base, GL, GT, GTI, GTI 16-Valve, GTI 8-Valve | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L GAS
- Jetta | 1997-1999, 1987-1992 | Base, Carat, GL, GLI 16-Valve, TDI, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Knuckle Part Number: 1H0-407-255
$252.54 MSRP: $345.00
You Save: $92.46 (27%)
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
- Position: Left
Fits the following Volkswagen Models:
- Corrado | 1992-1994 | SLC | 6 Cyl 2.8 L GAS
- Golf | 1995-1998 | GTI VR6 | 6 Cyl 2.8 L GAS
- Jetta | 1994-1999 | GLX | 6 Cyl 2.8 L GAS
- Passat | 1995-1997 | GLX | 6 Cyl 2.8 L GAS
View More
View related parts
Volkswagen Knuckle Part Number: 1H0-407-256
$253.64 MSRP: $346.50
You Save: $92.86 (27%)
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
Fits the following Volkswagen Models:
- Corrado | 1992-1994 | SLC | 6 Cyl 2.8 L GAS
- Golf | 1995-1998 | GTI VR6 | 6 Cyl 2.8 L GAS
- Jetta | 1994-1999 | GLX | 6 Cyl 2.8 L GAS
- Passat | 1993-1997 | GLX | 6 Cyl 2.8 L GAS
View More
View related parts
Volkswagen Steering Knuckle Part Number: 191-407-255-B
$260.59 MSRP: $356.00
You Save: $95.41 (27%)
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Left
Fits the following Volkswagen Models:
- Golf | 1985-1987 | Base, GL, GT, GTI, GTI 16-Valve | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
- Jetta | 1985-1987 | Base, GL, GLI, GLI 16-Valve, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
View related parts
Volkswagen Steering Knuckle Part Number: 191-407-256-B
$260.59 MSRP: $356.00
You Save: $95.41 (27%)
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Right
Fits the following Volkswagen Models:
- Golf | 1985-1987 | Base, GL, GT, GTI, GTI 16-Valve | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
- Jetta | 1985-1987 | Base, GL, GLI, GLI 16-Valve, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS
View related parts
Volkswagen Knuckle Part Number: 191-407-255-C
$261.29 MSRP: $356.95
You Save: $95.66 (27%)
ADD TO CART
Product Specifications
- Other Name: Housing; Steering Knuckle
- Position: Left
- Replaces: 191-407-255-D, 191-407-256-D
Fits the following Volkswagen Models:
- Golf | 1987-1992 | Base, GL, GT, GTI, GTI 16-Valve, GTI 8-Valve | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L GAS
- Jetta | 1987-1992 | Base, Carat, GL, GLI 16-Valve, Wolfsburg Edition | 4 Cyl 1.6 L DIESEL, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Knuckle Part Number: 701-407-312-G
$268.79 MSRP: $367.20
You Save: $98.41 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Right
Fits the following Volkswagen Models:
- EuroVan | 1997, 1995, 1993 | Camper, CL, GL, MV | 5 Cyl 2.5 L GAS, 6 Cyl 2.8 L GAS
View related parts
Volkswagen Knuckle Part Number: 701-407-311-G
$281.62 MSRP: $384.73
You Save: $103.11 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Left
Fits the following Volkswagen Models:
- EuroVan | 1993 | CL, GL, MV | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Knuckle Part Number: 1H0-407-255-B
$291.58 MSRP: $398.33
You Save: $106.75 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Left
Fits the following Volkswagen Models:
- Golf | 1997-1999 | GL, K2, TDI | 4 Cyl 1.9 L DIESEL
- Jetta | 1998 | TDI | 4 Cyl 1.9 L DIESEL
View related parts
Volkswagen Knuckle Part Number: 1H0-407-256-B
$291.58 MSRP: $398.33
You Save: $106.75 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing
- Position: Right
Fits the following Volkswagen Models:
- Golf | 1997-1999 | GL, K2, TDI | 4 Cyl 1.9 L DIESEL
- Jetta | 1998 | TDI | 4 Cyl 1.9 L DIESEL
View related parts
Volkswagen Knuckle Part Number: 3Q0-505-435-M
$348.20 MSRP: $475.68
You Save: $127.48 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Housing; Knuckle
- Position: Left
Fits the following Volkswagen Models:
- Arteon | 2019-2023 | SE, SE R-Line, SEL, SEL Premium, SEL Premium R-Line, SEL R-Line | 4 Cyl 2.0 L GAS

| Page 1 of 7 |Next >

1-20 of 121 Results

Volkswagen Steering Knuckle

Volkswagen Steering Knuckle is designed to be the tough pivot that allows front wheels to gently turn and keep suspension and brake parts in place. Since 1937 VW has been working towards the ideals of a reliable people car, a dream realized by icons such as the Beetle and the adaptable Type 2 van, and today that dream continues to live on in sleek sedans and growing ID electric models riding on the smart MQB platform. Many VW cars combine turbocharged TSI engines and direct fuel injection for lively power and solid fuel economy, while digital cockpits, touchscreen MIB infotainment, head-up displays and park assist introduce contemporary tech to the drive. Clean design goes hand in hand with rock-solid engineering, which makes every VW approachable yet advanced, giving families and first-time drivers confidence on highways and city streets. The same dedication to durability is evident on the inside of each front corner, where the essential Steering Knuckle connects the hub, control arms, strut, and tie-rod to one rigid assembly that maintains alignment true over bumps and hard braking. Whether the layout involves a lightweight spindle for non-driven wheels or a hub style that transmits torque from an axle, the component ensures smooth steering response and even tire wear for the entire lineup. Its strong casting is resistant to flex, its precise bores provide a secure bearing, and its design makes future service simple, adding to the dependable reputation that followers of the brand expect.

Buying OEM parts is a smart move to keep your long-term repair costs low. These components are built to last because VW uses such strict factory standards. At VWPartsGiant.com, it is easy to find genuine Volkswagen Steering Knuckle at prices that actually beat the competition. You get a real manufacturer's warranty with every single part, so you know your purchase is safe. Plus, forget about return headaches since our policy is easy and worry-free. We ship your order fast, too. If you have questions, our team of parts experts is ready to help. Why wait? Start shopping now!

Volkswagen Steering Knuckle Parts and Q&A

Knuckle
4B0-505-434-A
Q: How to remove and reinstall the rear Steering Knuckle and rear Wheel Hub in a vehicle's rear suspension components on Volkswagen Passat?
A:
Relax the wheel bolts and rear driveaxle hub bolt and then raise the back of the vehicle and place it on jackstands to make sure it is firmly secured. The next step is to take off the rear brake caliper, mount and brake disc bearing in mind to hold the caliper with a piece of wire or a piece of string to keep the hose away. And continue with the removal of the ABS rear wheel speed sensor. Position the camber adjusting cam relative to the lower control arm to maintain the camber positioning during reassembly and unscrew the nut on the other end of the bolt, remove the eccentric washer and draw the bolt. Unscrew the nut and take off the track rod-to-rear knuckle bolt then the upper control arm-to-rear knuckle bolt and then disassemble the knuckle and hub assembly. To install, it is necessary to reverse the steps used to remove the items, but be sure to install new hardware and make the match marks on the camber adjusting cam and the lower control arm and do not tighten any suspension fastener until the rear suspension is raised to replicate normal ride height, which prevents distortion of the bushings. Lastly, fully screw all suspension fasteners to desired torques, put brake disc and mounting bracket with caliper onto the car, and screw the brake fasteners to the correct torque before installing the wheel, screwing the bolts secure, and lowering the vehicle then screwing the bolts to recommended tightness.
Knuckle
5C0-407-255
Q: How to remove the hub and wheel bearing assembly when replacing the steering knuckle on Volkswagen Jetta?
A:
Disassemble the hub and the wheel bearing when the steering knuckle is to be replaced. The first step is to remove the wheel cover and loosen the driveaxle/hub bolt when the vehicle is on wheels, and then loosen the wheel bolts. Put the rear wheels in chock, use the parking brake, lift up the front of the car and place it safely on jackstands before removal of the front wheel. Then loosen the driveaxle/hub bolt and the ABS wheel speed sensor and brake caliper without dismounting the hose, secured the caliper to the coil spring to prevent any strain on the hose. Loosen a few turns of the balljoint-to-steering knuckle nut and then remove the tie-rod end of the steering knuckle and the balljoint of the control arm and part the balljoint and knuckle. Disconnect the front level control sensor arm with the control arm, in case equipped. Take the strut-to-knuckle nut out and hammer and punch out the bolt, taking care to make the opening where the strut inserts into the knuckle open wide where this might happen. Gently remove the knuckle assembly outwards and push the driveaxle out of the hub with a soft faced hammer to tap the CV joint out or a puller to loosen it out. secured driveaxle. To install, first install the balljoint into the knuckle and tighten the new nut to the required torque. Apply multi-purpose grease to the splines of the driveaxle, and then insert the knuckle/hub assembly in place and connect it to the driveaxle stub shaft, put a new driveaxle/hub bolt in place but not tightened. Attach the strut to the knuckle, and enter it as far as possible into the bore, and apply and organize the new nut and bolt to the required torque. Install the control arm to the balljoint and install and tighten new nuts to the recommended torque. Insert the tie-rod end into the steering knuckle and attach and tighten the new retaining nut. Install the caliper disc and caliper tighten the caliper mounting bracket bolts and caliper guide pin/mounting bolts to designated torque. Essentially, last but not least, screw the driveaxle/hub bolt on safely, screw in the ABS wheel speed sensor, replace the wheel again, lower the vehicle to the ground, and screw the driveaxle/hub bolt and wheel bolts to the required torque.
