How to raise the front and remove the harmonic balancer on Volkswagen Passat?

Lift the front of the car and place it on jackstands. Working underneath the car, take out the lower splash shield underneath the engine. Install radiator support panel in service position, it is important to note that the front of the engine is limited in accessibility and it will be required to remove the front bumper and place the radiator support panel as far as possible so as to be able to remove the surrounding parts. Take out the serpentine drivebelts. Loosen the bolts on the front of the crankshaft pulley and remove it off the engine. In case you are undertaking other operations on removing the crankshaft pulley, loosen the drive sprocket retaining bolt, and then loosen the crankshaft pulley. Removing this bolt is not advisable, provided you get a new one because it is not recommended to use what you have. When installing, make sure that the crankshaft drive sprocket bolt is tightened to a given specified torque and rotation angle. Install the crankshaft pulley/balancer on the crankshaft drive sprocket and orientate the mounting holes, the pulley fits only in a single orientation. Attach the pulley assembly bolts and screw them to the required torque. All the other installation processes are opposite to uninstallation.

Genuine Volkswagen Passat Harmonic Balancer

Engine Harmonic Balancer

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

18 Harmonic Balancers found

View related parts
Volkswagen Passat Crankshaft Pulley Part Number: 027-105-243
$161.88 MSRP: $226.72
You Save: $64.84 (29%)
ADD TO CART
Product Specifications
- Other Name: Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1990-1993 Volkswagen Passat | CL, GL | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Damper Part Number: 06B-109-477-A
$198.72 MSRP: $278.31
You Save: $79.59 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Belt Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2001-2005 Volkswagen Passat | GL, GLS, GLS 4 Motion | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 03G-105-243-B
$226.10 MSRP: $316.67
You Save: $90.57 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2004-2005 Volkswagen Passat | GL TDI, GLS TDI | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Pulley Part Number: 04L-105-243
$159.54 MSRP: $223.44
You Save: $63.90 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley, Vibration Damper
- Replaces: 03G-105-243
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015 Volkswagen Passat | TDI SE, TDI SEL Premium | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Damper Part Number: 058-198-479-A
$235.62 MSRP: $330.00
You Save: $94.38 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Repair Kit
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1998-1999 Volkswagen Passat | GLS | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Vibration Damper Part Number: 03H-105-243-N
$253.76 MSRP: $346.67
You Save: $92.91 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006 Volkswagen Passat | 3.6 | 6 Cyl 3.6 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 03H-105-243-P
$266.55 MSRP: $364.14
You Save: $97.59 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2018 Volkswagen Passat | GT, SE, SEL Premium | 6 Cyl 3.6 L GAS
View related parts
Volkswagen Passat Vibration Damper Part Number: 038-105-243-M
$262.29 MSRP: $358.31
You Save: $96.02 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2014 Volkswagen Passat | TDI SE, TDI SEL, TDI SEL Premium | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Pulley Part Number: 06H-105-243-K
$198.72 MSRP: $278.31
You Save: $79.59 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Replaced by: 06H-105-243-Q
- Replaces: 06H-105-243-G, 06H-105-243-F, 06K-105-243, 06K-105-243-D
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2014-2022, 2008-2010 Volkswagen Passat | Komfort, Limited Edition, Lux, R-Line, S, SE, SE R-Line, SEL, SEL Premium, Sport, Turbo, Wolfsburg Edition | 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 06A-105-243-E
$317.19 MSRP: $433.32
You Save: $116.13 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Vibration Damper
- Replaces: 06B-105-243-F
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1995-1996 Volkswagen Passat | GLS | 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Vibration Damper Part Number: 07D-105-243-J
$342.82 MSRP: $468.33
You Save: $125.51 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2002-2004 Volkswagen Passat | W8 | 8 Cyl 4.0 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 06B-105-243-D
$402.59 MSRP: $549.98
You Save: $147.39 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2001-2005 Volkswagen Passat | GL, GLS, GLS 4 Motion | 4 Cyl 1.8 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 07K-105-243-F
$411.74 MSRP: $562.49
You Save: $150.75 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Replaces: 07K-105-243-B
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2012-2014 Volkswagen Passat | S, SE, SEL, SEL Premium, Wolfsburg Edition | 5 Cyl 2.5 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 028-105-243-T
$415.58 MSRP: $567.74
You Save: $152.16 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Vibration Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1996-1997, 1990-1993 Volkswagen Passat | CL, GL, GLS, TDI | 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 038-105-243
$436.14 MSRP: $595.81
You Save: $159.67 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2015 Volkswagen Passat | TDI SE, TDI SEL Premium | 4 Cyl 2.0 L DIESEL
View related parts
Volkswagen Passat Pulley Part Number: 021-105-243-D
$477.02 MSRP: $651.67
You Save: $174.65 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Crankshaft Pulley, Vibration Damper
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1993-1997 Volkswagen Passat | GLX | 6 Cyl 2.8 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 037-105-243-A
$496.54 MSRP: $678.33
You Save: $181.79 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 1995-1997 Volkswagen Passat | GLS, TDI | 4 Cyl 1.9 L DIESEL, 4 Cyl 2.0 L GAS
View related parts
Volkswagen Passat Pulley Part Number: 03H-105-243-F
$690.64 MSRP: $870.92
You Save: $180.28 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Damper; Pulley
- Replaces: 03H-105-243
- Warranty: This genuine part is guaranteed by Volkswagen's factory warranty.
Fits the following Vehicles:
- 2006-2008 Volkswagen Passat | 3.6, VR6 | 6 Cyl 3.6 L GAS

Volkswagen Passat Harmonic Balancer

Choose OEM Harmonic Balancer for superior quality and long-lasting durability. They match the Volkswagen's factory specifications exactly and pass strict quality control. If you plan to replace Harmonic Balancer on your Passat, put OEM at the top of your list. You'll get the right fit, reliable performance, and peace of mind. We stock an extensive inventory of genuine Volkswagen Passat parts. It is easy to find what you need. You will love our competitive prices that help you save. No more hassle with returns or guesswork. Every part includes a warranty straight from the manufacturer. Get trusted quality, strong durability, and real value today.

Volkswagen Passat Harmonic Balancer Parts and Q&A

Pulley
03G-105-243-B
Q: How to raise the front and remove the harmonic balancer on Volkswagen Passat?
A:
Lift the front of the car and place it on jackstands. Working underneath the car, take out the lower splash shield underneath the engine. Install radiator support panel in service position, it is important to note that the front of the engine is limited in accessibility and it will be required to remove the front bumper and place the radiator support panel as far as possible so as to be able to remove the surrounding parts. Take out the serpentine drivebelts. Loosen the bolts on the front of the crankshaft pulley and remove it off the engine. In case you are undertaking other operations on removing the crankshaft pulley, loosen the drive sprocket retaining bolt, and then loosen the crankshaft pulley. Removing this bolt is not advisable, provided you get a new one because it is not recommended to use what you have. When installing, make sure that the crankshaft drive sprocket bolt is tightened to a given specified torque and rotation angle. Install the crankshaft pulley/balancer on the crankshaft drive sprocket and orientate the mounting holes, the pulley fits only in a single orientation. Attach the pulley assembly bolts and screw them to the required torque. All the other installation processes are opposite to uninstallation.
