Genuine Volkswagen Throttle Body
Fuel Injection Throttle Body- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
67 Throttle Bodies found
Volkswagen Throttle Body Part Number: 07K-133-062-A
$96.07 MSRP: $134.55You Save: $38.48 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Control Unit
Volkswagen Throttle Body Part Number: 021-133-064-A
$434.87 MSRP: $594.08You Save: $159.21 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Control Unit
Volkswagen Throttle Body Part Number: 035-133-063-DP
$494.10 MSRP: $675.00You Save: $180.90 (27%)Product Specifications- Other Name: Throttle; Lower Hose
Volkswagen Throttle Body Part Number: 07Z-131-063
$524.59 MSRP: $716.65You Save: $192.06 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Flap; Regulator Assembly
Volkswagen Throttle Body Part Number: 022-133-062-AB
$640.49 MSRP: $807.68You Save: $167.19 (21%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 06K-133-062-AN
$107.09 MSRP: $149.98You Save: $42.89 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle; Throttle Body
Volkswagen Throttle Body Part Number: 04E-133-062-T
$95.33 MSRP: $133.52You Save: $38.19 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Control Unit
Volkswagen Throttle Body Part Number: 04L-128-063-T
$233.28 MSRP: $326.69You Save: $93.41 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Control Unit; Throttle Body
- Replaces: 04L-128-063-P
Volkswagen Throttle Body Part Number: 037-133-061-BP
$153.51 MSRP: $215.00You Save: $61.49 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 023-133-061-A
$161.54 MSRP: $226.25You Save: $64.71 (29%)Product Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 06Q-133-062-A
$313.94 MSRP: $428.85You Save: $114.91 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 03F-133-062-E
$265.34 MSRP: $362.48You Save: $97.14 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 037-133-061-BK
$246.68 MSRP: $337.00You Save: $90.32 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 022-133-062-AG
$195.09 MSRP: $273.23You Save: $78.14 (29%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 037-133-063-M
$260.59 MSRP: $356.00You Save: $95.41 (27%)Product Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 044-133-061-F
$292.80 MSRP: $400.00You Save: $107.20 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 049-133-063-AC
$297.09 MSRP: $405.87You Save: $108.78 (27%)Product Specifications- Other Name: Throttle; Throttle Body
Volkswagen Throttle Body Part Number: 037-133-061-BJ
$306.71 MSRP: $419.00You Save: $112.29 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 027-133-063-S
$311.69 MSRP: $425.80You Save: $114.11 (27%)Product Specifications- Other Name: Throttle
Volkswagen Throttle Body Part Number: 027-133-063-BH
$321.35 MSRP: $439.00You Save: $117.65 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Throttle
- Replaced by: 027-133-063-BB
| Page 1 of 4 |Next >
1-20 of 67 Results
Volkswagen Throttle Body
The Volkswagen Throttle Body meters incoming air exactly so each tap of the accelerator feels crisp and fuel use remains low. For over 80 years VW has pursued the dream of a comfortable yet advanced ride, from the iconic Beetle that put millions on the road to the clever Type 2 van that hauled families and surfboards with equally deft ease, and the brand continues its drive towards TSI turbo engines, the flexible MQB platform, digital cockpit displays, park assist and a growing ID line of electric vehicles. Each VW merges clean styling with solid build quality and even base models often have touchscreen MIB infotainment and head-up displays that make day-to-day driving fun and easy. This focus on user-friendly tech is a perfect match to engines that love to rev and the company's reputation for reliability ensures durability remain high worldwide. Inside the intake system, the Throttle Body is located immediately after the air filter and it operates a butterfly valve that is connected either by a cable or drive-by-wire motor to control the airflow, which in turn sends signals to the control module to adjust the fuel injection instantly to provide smooth power and low emissions. Modern sensors monitor the angle of the blades and idle passages to keep the engine calm in traffic but ready to surge when you put your foot to the floor, demonstrating that one clever part can ensure VW efficiency across the entire lineup.
Buying OEM parts is a smart move to keep your long-term repair costs low. These components are built to last because VW uses such strict factory standards. At VWPartsGiant.com, it is easy to find genuine Volkswagen Throttle Body at prices that actually beat the competition. You get a real manufacturer's warranty with every single part, so you know your purchase is safe. Plus, forget about return headaches since our policy is easy and worry-free. We ship your order fast, too. If you have questions, our team of parts experts is ready to help. Why wait? Start shopping now!
Volkswagen Throttle Body Parts and Q&A
- Q: What steps must be taken to properly remove and install a throttle body control module after disconnecting the battery on Volkswagen Jetta?A:This means that there are a number of systems that have to be re-teamed whenever the battery is disconnected in order to work well. With the addition of a new throttle body control module, the program in the Engine Control Module (ECM) will have to be rewritten using the factory scan tool. Start by removing the cable of the negative battery terminal and the engine cover. In 1.4L engines, take off air filter housing, disconnect air charge pressure sensor connector, disconnect emission hoses on the clips on the intake air duct, disconnect hose on the duct, loosen clamps holding duct to throttle body and to turbocharger outlet, disconnect throttle body electrical connector, remove four bolts and bracket and remove throttle body off the intake manifold, and installing it is the opposite of the way to remove it. In 1.8L and 2.0L turbocharged engines, lift the vehicle on jackstands, undo the charge air pipe fasteners, unplug the electrical connector of the charge air pipe, unclamp the clamps on each end of the charge air pipe, unplug the electrical connector of throttle body, unscrew the mounting fasteners of throttle body and carefully remove throttle body off the intake manifold, being careful not to drop the throttle body gasket and cover the opening in the intake manifold with a clean shop towel In case of 2.0L non-turbocharged engines, the intake air hose clamp on the throttle body is loosened, the throttle body electrical connection is disconnected, the four bolts are removed and the throttle body is detached, checking the throttle body seal condition. In the case of 2.5L engines, disconnect the vent hose, the secondary air injection pump hose and air inlet pipe clamp, disconnect the air inlet pipe and in some cases, remove the air guide connector-to-radiator support fasteners. Please detach the electrical connector and vent hose, remove throttle body mounting fasteners, take throttle body off intake manifold with care, clamping off coolant lines where necessary, changing hose clamps where necessary, inspect throttle body gasket, covering intake manifold aperture, snapping throttle body fasteners to correct torque.
- Q: How to replace the throttle body on Volkswagen Passat?A:In a four-cylinder engine, start by starting with removing of the air intake duct between throttle body and Mass Airflow sensor and then disconnecting the electrical connector to throttle control module. Empty the coolant and remove the hoses that are attached to the throttle body and then remove the accelerator cable. Unscrew the mounting bolts and remove the throttle body and screw the new throttle body on with a gasket and tighten the mounting bolts to the required tightness. The rest of the installation is performed in reverse sequence of removal and make sure to refill and bleed the cooling system. In case of V 6 engines, the starting point is to disassemble the engine cover and the air intake system between the Mass Airflow sensor and the intake air elbow. When it has a cruise control, disconnect the servo unit with the vacuum hose, remove the bolts attaching the bracket, disconnect the throttle rod and remove the servo unit. Unplug the electrical connectors of the intake air temperature sensor, secondary air injection solenoid valve, and intake manifold tuning solenoid valve and label each vacuum hose carefully and notate the hose before removing the valve bracket assembly. The next step is to take off the air intake elbow off the throttle body, the electrical connector off throttle control module, empty the coolant and disconnect the hoses of the throttle body. Unattach the cable of accelerator, unscrew the mounting bolts and remove throttle body and examine the O-ring seal to replace in case of need. Install throttle body and attach the bolts with a specified torque and install the throttle body in reverse sequence with the perspective of filling and bleeding the cooling system.
